A3200MG004E

Sensor	IMX290
Image Sensor	1/2.8″CMOS
Shutter	Rolling
Resolution	1920 × 1080
Frame Rate	22 fps
Bit Depth	10
Mono/Color	Mono
Pixel Size	2.9 μm × 2.9 μm
Pixel	2.07MP
S/N Ratio	>38dB
Dynamic Range	Support DOL-HDR
Image Format	Mono8
Binning	Support
ROI	Support
Gain	1~32
Gamma	From 0 to 4, support LUT
Exposure Time	17.5μS~1S
Trigger Mode	Software Trigger/Hardware Trigger/Free Run Mode
SPC	Support
User Setting	Support two sets of user-defined configurations
Image Buffer	256MB
Port	GigE, PoE
GPIO Interface	1x 6 pin Hirose: 1x Opto-isolated input, 1x Opto-isolated output, 1 configurable input and output
Lens Mount	C-mount
Power Supply	PoE/ DC 9V~24V power supply via Hirose interface
Power Consumption	12V≈3.3W
Product Dimensions	29mm×29mm×42mm
Net Weight	88 g
Storage Temperature	-30℃~+80℃
Operating Temperature	0℃~+50℃

Descriere

Gigabit Ethernet interface, providing 1Gbps bandwidth with a maximum transmission distance of 100m
256MB on-board cache for data transmission or image resend
Support Software Trigger/Hardware Trigger/Free Run Mode
Support ISP functions including Sharpness/Denoising/Gamma/LUT/BlackLevel Correction/TargetBrightness/Contrast etc.
Color cameras support interpolation, white balance, color conversion matrix, chroma, saturation, etc.
Support multiple image data formats output/ROI/Mirror, etc.
Conform to GigE Vision V2.0 protocol and GenICam standard
Support PoE power supply, DC 9V~24V wide voltage power supply
Conform to CE, FCC, RoHS

Binning	Support
Bit depth	10
Dynamic range	Support DOL-HDR
Exposure time	17.5us~1S
Frame rate	22 fps
Gain	1~32
Gamma	From 0 to 4，support LUT
Gpio interface	1x 6 pin Hirose: 1x Opto-isolated input, 1x Opto-isolated output, 1 configurable input and output
Image buffer	256MB
Image format	Mono8
Image sensor	1/2.8"CMOS
Lens mount	C-mount
Pixel	2.07MP
Pixel size	2.9 um x 2.9 um
Port	GigE, PoE
Power consumption	12V≈3.3W
Power supply	PoE/ DC 9V~24V power supply via Hirose interface
Resolution	1920 x 1080
Roi	Support
Sensor	IMX290
Shutter	Rolling
Spc	Support
Storage temperature	-30℃~+80℃
Trigger mode	Software Trigger/Hardware Trigger/Free Run Mode
User setting	Support two sets of user-defined configurations
Mono-color	Mono
S/n ratio	>38dB
